Description
Feature: Du Pont TPEE insulated.
Rating: 80 deg C, 300 Vac.
Conductor Size: 32 ~ 24AWG.
Conductor Quantity: 2 ~ 50 cores.
Insulation Material: LSZH complied TPEE.
Jacket Material: LSZH complied Polyurethane PUR.
Executed Standard: Appliance Wiring Material UL 758.
Application: Internal wiring or external interconnection of appliances or electronic equipment.
UL20549 TPEE-PUR High Temperature Resistant Spring Cable
| Style Number |
Cores | Conductor | Insulation Thickness |
Insulation Diameter |
Shield Coverage |
Jacket Thickness |
Overall Diameter |
Conductor Resistance |
|
| AWG | No/mm | mm | mm | % | mm | mm | Ω/KM | ||
| UL20549 | 2C | 24 | 11/0.16 | 0.23 | 1.10 | >=65 | 0.86 | 4.60 | 94.20 |
| 3C | 24 | 11/0.16 | 0.23 | 1.10 | >=65 | 0.86 | 4.70 | 94.20 | |
| 4C | 24 | 11/0.16 | 0.23 | 1.10 | >=65 | 0.86 | 5.00 | 94.20 | |
| 5C | 24 | 11/0.16 | 0.23 | 1.10 | >=65 | 0.86 | 5.20 | 94.20 | |
| 6C | 24 | 11/0.16 | 0.23 | 1.10 | >=65 | 0.86 | 5.70 | 94.20 | |
Packaging & Delivery
Packaging Details: 200pcs per carton
Delivery Lead Time: 10 days for delivery
Supply Ability: 100,000pcs per week
Port: Guangzhou
Technical Support
UL20549 is a safety style number for electronic connection application, user can designate the cable structure and conductor size to create a customized cable as desired.
